Which wireless standard suits you best?

07 September 2015

Tom McKinney of HMS Industrial Networks offers a review of the available short range wireless standards for industrial applications.

Recently the buzz around Industrial IoT has grown to a deafening roar. The market for IIoT devices is projected to grow exponentially over the next several years as businesses start to capture more data regarding their operations.  That data will be used to monitor and optimize processes, and as companies learn to use the data they capture to improve processes, the result will be increased productivity. Beyond internal productivity, this data may lead to improved company-to-company operations benefiting both the producer and the customer.

Multiple technology advancements have converged to make large-scale Industrial IIoT deployments possible.  These advancements include reduced cost of data storage, lower power RF solutions and higher levels of network accessibility.  Another important enabler for Industrial IoT is wireless standardization.

Wireless is nothing new

Wireless networks have been used for over 30 years in the industrial market. In the past, these networks were typically sub 1GHz proprietary systems. The solutions used simple modulation techniques like amplitude-shift keying (ASK) or frequency-shift keying (FSK). Radios that supported these types of modulation could be created easily with a handful of discrete parts. The drawback of these solutions were a complete lack of security and limited bandwidth.

Over the last twenty years, several standards have been developed to define robust radio solutions. The most recent standards are secure enough for broad deployment. In addition, several new free-to-use frequency bands where introduced in the 80s including the 2.4GHz and 5GHz bands. Deploying a standardized radio solution today is a cost-effective secure way to both monitor and control devices in the field or factory. Given the number of wireless standards to choose from, the question becomes which standard is the right standard to deploy.

So let's take a look at the three most common wireless standards deployed in the 2.4GHz band: Bluetooth, WiFi and Zigbee.

WiFi

WiFi or IEEE 802.11a/b/g/n is the widest deployed consumer and enterprise wireless TCP/IP network solution. WiFi is short for Wireless Fidelity and is a standard used to identify Wireless Local Area Network (WLAN) devices. The committee managing this standard is aims to create the best possible wired TCP/IP network replacement.  The committee prioritizes security and speed over all other tradeoffs. As a result, 802.11n has the highest bandwidth of any short range wireless standard. The drawback is power consumption and processing power required to effectively manage the 802.11 stack. These drawbacks created a gap in the market and several standards have emerged to address the very low power wireless market.

Bluetooth

Bluetooth and Zigbee were both introduced to address markets not serviced well by WiFi. The Bluetooth standard addressed the needs for a low power Personal Area Network (PAN).  A PAN is defined as the network that surrounds a person or a smart device.  The requirements include fast association, simple human-to-machine interfaces and low power. In a PAN, multiple transmitters can be placed very close together - Bluetooth includes timing to ensure device transmitters don´t overlap.  Bluetooth was also designed under the assumption it would have to co-exist with WiFi and includes a frequency hopping algorithm to ensure Bluetooth messages can get through even when multiple WiFi channels are active.   Finally, because Bluetooth uses a very low power transmitter, it is less sensitive to multi-path compared to WiFi. As a result, Bluetooth can be deployed successfully without extensive RF site reviews and planning. The system is very resistant to noise and interference.

Zigbee

Zigbee is based on IEEE 802.15.4 which is a general-purpose, low-power wireless radio standard that allows different protocols to be built on top of the standard radio.  Zigbee set out to support low power sensor networks capable of covering a large area.  Zigbee uses meshing networking and a very aggressive power profile to meet the needs of this niche market.  Zigbee´s protocol is designed for quick turn-on and turn-off, thereby saving power.   Several other protocols have been built on top of 802.15.4 including ISA100, WirelessHART and 6LoWPAN.

Bluetooth Low Energy

Bluetooth Low Energy (BLE) was introduced as an update to the Bluetooth standard.  Leveraging some of the techniques used in 802.15.4, BLE was able to achieve even lower power points when compared to Zigbee and support many of the features originally created by the Zigbee standards effort.

Selecting the standard for you

So which standard is the right standard to deploy? That depends on the system requirements.  In summary, WiFi has the highest bandwidth and most comprehensive stack but Bluetooth, BLE and Zigbee offer features ideal for particular applications.  For example, if monitoring battery-powered sensors over a very large area, Zigbee would be the ideal standard. Bluetooth/BLE works well as a cable replacement point-to-point technology or for monitoring sensors over a smaller area.  BLE has a huge installed base of tablets and phones making it an excellent choice for human-to-machine interfaces.

Although technology standards may vary, there is no doubt that more and more applications will be wirelessly connected in the near future. With the advent of Industrial IoT, billions of devices will need to hook up to the Internet, and many of these connections will undoubtedly be wireless.

Summary of the pros and cons of each standard:

1)    WiFi

    a.    Pros
           i.    Highest Bandwidth up to 600Mbits/s with 802.11n
           ii.    Fixed 25 MHz or larger Channels
           iii.    Support for 2.4 and 5GHz channels
           iv.    Extensive security features
    b.    Cons
           i.    Range is lower with higher data rates and 5GHz

           ii.    Not a good match for battery powered sensors

2)    Bluetooth/BLE

    a.    Pros
          i.    Very low power
          ii.    Massive deployed
          iii.    Very good performance in congested or noisy wireless environments
          iv.    Ease of use, no frequency planning or site map requirements
    b.    Cons
           i.    Max data rate of 2Mbits/s
           ii.    No automated roaming standard



3)    Zigbee

    a.    Pros
           i.    Very low power
           ii.    Fixed channels between WiFi channels in 2.4 GHz band
           iii.    Support for sub 1GHz bands
    b.    Cons
           i.    Complicated mesh network
           ii.    Max bandwidth of 250Kbits/s
