B&R Power Panel T-Series and C-Series

The terminal series is being offered with four TFT display sizes ranging from 4.3" to 10.1" and comes with 2 Ethernet interfaces, 2 USB ports and an extensive array of configuration options. Both series are competitively priced and open up new possibilities to machine builders working in cost sensitive markets.

The Power Panel C70 controller is equipped with a 333 MHz Intel Atom CPU, 256 MB DDRAM, 16 kB FRAM and 2 GB on board flash drive. This controller provides a built-in touch screen and is being offered in three display sizes ranging from 5.7" to 10.1". The Power Panel C70 achieves cycle times down to 1ms. POWERLINK and standard Ethernet, 2x USB 2.0 and X2X Link, as well as optional RS232, RS485 and CAN interfaces meet all connection requirements.

T-Series and C-Series Power Panels are available in portrait and landscape format in anthracite grey with pinstripes and aluminium white with pinstripes. These options are available in all sizes.
