Making twins truly identical starts at the signal boundary

EVERY DIGITAL twin depends on a signal chain that translates physical behaviour into digital information. Vibration, torque, pressure, current and temperature all begin as analogue signals that must be conditioned, filtered and converted before they can be used in a model.

Each stage in that chain introduces constraints. Some are expected, such as bandwidth and resolution limits, while others are more subtle, including timing variation between channels, drift introduced by temperature changes or noise created by layout and grounding decisions.

These effects rarely appear as clear faults. Correlations weaken until the twin’s outputs diverge from what operators observe at the machine. At that point, the challenge is no longer about data volume or model complexity. It is about whether the measurement system is preserving the relationships that the model depends on.

As digital twins move closer to control loops, timing consistency becomes central. Vision systems guiding motion, servo-controlled stations and multi-sensor condition monitoring setups all rely on aligned signals. If timing shifts across channels, even slightly, relationships between measurements begin to degrade. The model may still process data correctly, but it is no longer working from a coherent view of the system.

The analogue-to-digital boundary is the critical point

The most important design decisions in any digital twin architecture sit at the point where analogue signals become digital data. Latency variation shifts phase relationships across channels. Noise introduced early in the signal chain creates artefacts that a model can interpret as machine behaviour. Drift across operating conditions erodes alignment with reality even when numerical outputs remain stable.

Modern automation systems increase the pressure on this boundary. Higher sensor density increases the number of channels that need capture plus alignment. A motion axis may combine encoder feedback with inertial sensing, then current measurement adds drive context. Process equipment often requires pressure aligned with flow to support stable control behaviour.

The value of the twin comes from these relationships, not from any individual signal. That makes synchronisation a core requirement rather than a design detail.

General-purpose processing platforms play an important role in automation systems, particularly for coordination and higher-level control. But they were never designed for reliable, multi-channel measurement systems over long periods with microsecond-level stability. Software can reduce some variability, but it cannot fully remove constraints introduced at the point of acquisition.

Designing the acquisition layer as a system

Mixed-signal ASICs address this challenge by treating data acquisition as a single integrated system rather than a set of discrete components. When signal conditioning, amplification, filtering and conversion are designed together, timing and signal integrity can be controlled more precisely at the point of capture.

This improves alignment between channels and reduces latency variation, supporting a twin that represents dynamic behaviour more consistently. It also improves stability over time, particularly in environments where temperature, vibration and electrical noise would otherwise introduce drift.

Integration has additional practical benefits. Fewer discrete components reduce board complexity and shorten analogue paths, which improves electromagnetic performance and mechanical robustness. These factors matter in industrial environments where systems run continuously, and maintenance windows are limited.

Ownership of the full signal chain also changes how performance is validated. When analogue and digital stages are designed together, calibration and test processes can reflect real operating conditions rather than isolated component specifications, which tends to produce more predictable behaviour once systems are deployed.

Surviving deployment

The value of accurate data acquisition becomes most visible once digital twins are used to support operational decisions.

In automotive manufacturing, tightly aligned vibration and electrical measurements allow earlier detection of bearing degradation. In process industries, stable pressure and flow data help distinguish mechanical issues from normal variation. These outcomes come from improving the stability and coherence of the data feeding the model.

That distinction becomes more important as edge analytics and embedded intelligence move closer to real-time control. In many systems, inference is no longer separate from operation. It sits alongside motion control, PLC logic and safety systems, which increases the importance of reliable data acquisition. At that point, the signal layer becomes part of the control architecture itself rather than a supporting function.

Digital twins now influence live production decisions, and that influence places pressure on the quality of the data that underpins them. Accuracy cannot be restored later once capture has introduced timing skew or drift.

For manufacturers developing digital twin strategies, this makes data acquisition a foundational design concern. Synchronisation, drift control and timing stability determine whether a model remains aligned with reality over time. A digital twin is only as accurate as the signals it is built on. That accuracy is decided at the boundary where silicon first translates the physical world into data.

Ross Turnbull is a director at Swindon Silicon Systems
