Ultra-slim brake

The unit has been developed by using extremely high energy permanent magnets to obtain its high torque in a small space. The brake has a small outside diameter and a brake field of less than 13mm, with a comparatively large bore through the centre for the application’s drive shaft.

The design engineers at SG Transmission were also faced with the challenge of designing an efficient magnetic circuit to fit in such a small envelope, which incorporated the coil to de-energise the brake.

Paul Short, technical manager at SG Transmission, said: “We initially designed this product for a customer who had an already specified envelope size. We achieved the desired specification in a very limited time scale to meet the customer’s expectations.”

“Since providing this solution for the customer we have further developed the brake, after receiving a number of enquiries from customers regarding the high torque brake within a small space.”

The high torque brake is suitable for most industries including robotics, medical and military due to its inherent backlash-free construction. Additionally, it is low in power consumption which reduces heat build-up when compared to spring applied alternatives.
