Compact motor controller
16 June 2016
Designed to control 12 or 24V DC motors in applications where special functions are required is the EM-241A drive from Finnish motor controller manufacturer, Electromen OY, available through OEM Automatic.
The controller, measuring 42x72mm with an output of 15A max continuous is built to be compact and cost effective. Functionality includes speed control (set or variable), bi-directional, soft start/stop, adjustable current limiting, load compensation, various fault trips/outputs and inputs for limit switches for end of travel.
Settings for the controller are accessed through either the handheld interface or USB connection and PC software. A DIN rail mount is available for fitting the controller inside a control panel or plastic/metal enclosure options are also available.
There is also a lower current version EM-324 at 4A max continuous and a higher current version EM-243A at 50A max continuous.
